Mirka® PBS Pneumatic Belt Sander 10NV 10x330mm Non Vacuum

The Mirka® Pneumatic Belt Sander is your optimal tool for weld marks and seams, rust removal, paint removal as well as for general grinding. Simply an ample sander for panel beating. All adjustments, such as setting the speed and the angle, and changing the belt, are hassle-free, quick and easy. No sweat nor bad words needed.


Regulator for smooth speed control, no tools required. The tension arm mechanism makes changing the belt both simple and fast. Setting the angle of the arm is effortlessly done as the hex key needed to arm adjustments is cleverly integrated into the handle, thus always at hand.


The rubber-coated handle makes the sander comfortable to hold and prevents it from getting cold. We care about your, and your co-worker’s, health and comfort, and the low vibrations and low noise level of our sanders make them a dream to work with, for both you and the ones around you.

Use for

Sanding

Technical details

Air Consumption
610 l/min
Belt Length
330 mm
Belt Width
10 mm
Max Speed (rpm)
17000 rpm
Noise Level, LpA (dB)
83.8 dB
Power Input (W)
417.6 W
Sander Type
Pneumatic
Sound power level (LWA)
94.8 dB(A)
Vibration emission uncertainty K *
0.68 m/s²
Vibration Level (m/s²)
1.88 m/s²
Weight
0.81 kg
Work Pressure (bar)
6.2 bar

Downloads

PDF

Exploded View - PBS Belt Sander 10NV

PDF

Mirka® PBS Belt Sander Leaflet

PDF

Manual - Mirka® PBS
